In this tutorial we will be creating a
basic responsive navigation menu with dropdown using only HTML and CSS.
Many navigation menus (especially responsive ones) are created using a
combination of HTML, CSS and Javascript. This simple CSS only method
will demonstrate that Javascript isn't always necessary!
The code we will create includes only the most
essential CSS required for structure and basic styling. This makes it
much easier to follow and understand the purpose of each line of code.
It also means that the end product is primed and ready for your unique
customization.
Live Demo
A Quick Message
Big thanks to the commenters that informed us of an issue this code
was having on mobile devices! We have now amended the code using the
checkbox method found here: http://bit.ly/1pMflzW as suggested by Sean
Savoie.
The HTML
As you can see I have declared the HTML5 doctype, and included the basic page structure. The only content within the
body
tags is a nested unordered list. To demonstrate which top level links
will have dropdowns, I have included a unicode down arrow (￬).
<!doctype html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>CSS Only Navigation Menu</title>
<meta name="viewport" content="width=device-width, initial-scale=1">
<link rel="stylesheet" href="style.css">
</head>
<body>
<ul id="menu">
<li><a href="#">Home</a></li>
<li>
<a href="#">About ￬</a>
<ul class="hidden">
<li><a href="#">Who We Are</a></li>
<li><a href="#">What We Do</a></li>
</ul>
</li>
<li>
<a href="#">Portfolio ￬</a>
<ul class="hidden">
<li><a href="#">Photography</a></li>
<li><a href="#">Web & User Interface Design</a></li>
<li><a href="#">Illustration</a></li>
</ul>
</li>
<li><a href="#">News</a></li>
<li><a href="#">Contact</a></li>
</ul>
</body>
</html>
The CSS
First of all, some basic styling to the ul and li elements to remove
bullet points and other list styles. The inline-block and float:left
attributes make the list display horizontally.
/*Strip the ul of padding and list styling*/
ul {
list-style-type:none;
margin:0;
padding:0;
position: absolute;
}
/*Create a horizontal list with spacing*/
li {
display:inline-block;
float: left;
margin-right: 1px;
}
The following attributes are almost exclusively for aesthetic appeal.
If you intend to style this menu to your liking then this is the
section of code to fiddle about with.
/*Style for menu links*/
li a {
display:block;
min-width:140px;
height: 50px;
text-align: center;
line-height: 50px;
font-family: "Helvetica Neue", Helvetica, Arial, sans-serif;
color: #fff;
background: #2f3036;
text-decoration: none;
}
/*Hover state for top level links*/
li:hover a {
background: #19c589;
}
/*Style for dropdown links*/
li:hover ul a {
background: #f3f3f3;
color: #2f3036;
height: 40px;
line-height: 40px;
}
/*Hover state for dropdown links*/
li:hover ul a:hover {
background: #19c589;
color: #fff;
}
Next up, some styling for the dropdown links. The first class defines
that the dropdown will not be visible by default. And the final class
says that the dropdown element will become visible on top level link
hover.
/*Hide dropdown links until they are needed*/
li ul {
display: none;
}
/*Make dropdown links vertical*/
li ul li {
display: block;
float: none;
}
/*Prevent text wrapping*/
li ul li a {
width: auto;
min-width: 100px;
padding: 0 20px;
}
/*Display the dropdown on hover*/
ul li a:hover + .hidden, .hidden:hover {
display: block;
}
The navigation menu is ready for desktop use now, however we should
also include some love for mobile users. Using a media query I target
devices with a max width of 760px and make a few changes to the code.
/*Responsive Styles*/
@media screen and (max-width : 760px){
/*Make dropdown links appear inline*/
ul {
position: static;
display: none;
}
/*Create vertical spacing*/
li {
margin-bottom: 1px;
}
/*Make all menu links full width*/
ul li, li a {
width: 100%;
}
}
Optional Final Step
Space is limited on mobile devices, so it would be cool if we also
had a button prompting mobile users to click a button before displaying
the whole menu. To do this a couple of lines of code to the HTML where
you want the button to appear.
<label for="show-menu" class="show-menu">Show Menu</label>
<input type="checkbox" id="show-menu" role="button">
Add the following code into the CSS anywhere
outside the media query:
/*Style 'show menu' label button and hide it by default*/
.show-menu {
font-family: "Helvetica Neue", Helvetica, Arial, sans-serif;
text-decoration: none;
color: #fff;
background: #19c589;
text-align: center;
padding: 10px 0;
display: none;
}
/*Hide checkbox*/
input[type=checkbox]{
display: none;
}
/*Show menu when invisible checkbox is checked*/
input[type=checkbox]:checked ~ #menu{
display: block;
}
And this code
within the media query:
/*Display 'show menu' link*/
.show-menu {
display:block;
}
Complete Code
HTML:
<!doctype html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>CSS Only Navigation Menu</title>
<meta name="viewport" content="width=device-width, initial-scale=1">
<link rel="stylesheet" href="style.css">
</head>
<body>
<label for="show-menu" class="show-menu">Show Menu</label>
<input type="checkbox" id="show-menu" role="button">
<ul id="menu">
<li><a href="#">Home</a></li>
<li>
<a href="#">About ￬</a>
<ul class="hidden">
<li><a href="#">Who We Are</a></li>
<li><a href="#">What We Do</a></li>
</ul>
</li>
<li>
<a href="#">Portfolio ￬</a>
<ul class="hidden">
<li><a href="#">Photography</a></li>
<li><a href="#">Web & User Interface Design</a></li>
<li><a href="#">Illustration</a></li>
</ul>
</li>
<li><a href="#">News</a></li>
<li><a href="#">Contact</a></li>
</ul>
</body>
</html>
CSS:
/*Strip the ul of padding and list styling*/
ul {
list-style-type:none;
margin:0;
padding:0;
position: absolute;
}
/*Create a horizontal list with spacing*/
li {
display:inline-block;
float: left;
margin-right: 1px;
}
/*Style for menu links*/
li a {
display:block;
min-width:140px;
height: 50px;
text-align: center;
line-height: 50px;
font-family: "Helvetica Neue", Helvetica, Arial, sans-serif;
color: #fff;
background: #2f3036;
text-decoration: none;
}
/*Hover state for top level links*/
li:hover a {
background: #19c589;
}
/*Style for dropdown links*/
li:hover ul a {
background: #f3f3f3;
color: #2f3036;
height: 40px;
line-height: 40px;
}
/*Hover state for dropdown links*/
li:hover ul a:hover {
background: #19c589;
color: #fff;
}
/*Hide dropdown links until they are needed*/
li ul {
display: none;
}
/*Make dropdown links vertical*/
li ul li {
display: block;
float: none;
}
/*Prevent text wrapping*/
li ul li a {
width: auto;
min-width: 100px;
padding: 0 20px;
}
/*Display the dropdown on hover*/
ul li a:hover + .hidden, .hidden:hover {
display: block;
}
/*Style 'show menu' label button and hide it by default*/
.show-menu {
font-family: "Helvetica Neue", Helvetica, Arial, sans-serif;
text-decoration: none;
color: #fff;
background: #19c589;
text-align: center;
padding: 10px 0;
display: none;
}
/*Hide checkbox*/
input[type=checkbox]{
display: none;
}
/*Show menu when invisible checkbox is checked*/
input[type=checkbox]:checked ~ #menu{
display: block;
}
/*Responsive Styles*/
@media screen and (max-width : 760px){
/*Make dropdown links appear inline*/
ul {
position: static;
display: none;
}
/*Create vertical spacing*/
li {
margin-bottom: 1px;
}
/*Make all menu links full width*/
ul li, li a {
width: 100%;
}
/*Display 'show menu' link*/
.show-menu {
display:block;
}
}
Conclusion & Live Demo
Live Demo
This code should work just fine in modern browsers, and doesn't rely
on any javascript which can slow down page load times. Be sure to check
out the live demo and use the code however you like!
